Features
THREE-WAY, HORN-LOADED EFFICIENCY
La Scala’s three-way, horn-loaded system delivers exceptional efficiency. For the AL6, we couple each driver to a precisely measured horn and optimize it for one of three pass-bands. This design generates greater acoustic power with less wattage, producing crystal clear sound with minimal distortion across the frequency spectrum.
EXTENDED PHASE PLUG FOR HEAVENLY HIGHS
We’ve paired our K-771 compression driver with a new, patented, extended phase plug to prevent cancellations and equalize wavelengths for cleaner dispersion. That means you get more coverage and clarity than ever before.
3” COMPRESSION DRIVER PUMPS UP THE POWER
Our new, midrange K-1133-HP compression driver adds a full inch to the drivers on previous AL5 models. The larger compression area increases sound pressure to the horn’s throat for more voluptuous volume.
SPREAD THE SOUNDSTAGE WITH MUMPS AND TRACTRIX TECHNOLOGY
The AL6 gets the Tractrix treatment. The new K-406M patented Tractrix midrange horn features a shorter, 2” throat for unparalleled presence and precision. Mumps technology improves coverage, adding small contours to help maintain frequency response to the horn’s edge.
BRING OUT THE BASS
For the first time, La Scala upgrades to a patented horn loaded, vented system, maximizing efficiency, extending output, and lowering distortion – realizing the benefits of both a horn-loaded system and a bass reflex system. The K-281 12” woofer with folded horn, sits comfortably in a new enclosure, producing richer and more robust bass from any room placement.
OPTIONAL HERITAGE ACTIVE CROSSOVER EXTENDS PERFORMANCE
Users have the option to add the Heritage Active Crossover tuned specifically for the La Scala speakers. Trickle-down technology from our heralded Jubilee floorstanding speakers, the Heritage Active DSP aligns time and phase while boosting frequencies and balancing EQ for a flat, color-free response.
REDESIGNED INPUT/OUTPUT PANEL
To accommodate the optional Heritage Active Crossover and give listeners more options, we’ve modified the I/O panel. It now includes passive and active inputs and a passive output, so switching setups is easy. We’ve also moved the panel to the speaker’s back for a cleaner look from almost any angle.
Specifications
General
Series
La Scala
Speaker Type
Indoor
Color
Walnut
Manufacturer Color
Walnut
Frequency Response
40Hz-19kHz (+/- 4 dB), 1/4 space anechoic
Sensitivity
103dB, Pink noise, 2.83V, 1m, 40 Hz-19kHz
Impedance
8 ohms
Power Handling
100 W
Inputs/Outputs
Information
Inputs: 5 way metal binding post
Features
Technologies
Tractrix Technology
Additional Information
• Peak Power: 400W
• Enclosure Material: Veneered MDF
• Maximum SPL: 120dB, pink noise, 1m, 20v, 40Hz-19kHz
• Nominal Impedance: 8 ohms, 3.2 ohm minimum at 70Hz
• Enclosure Material: Veneered MDF
• Maximum SPL: 120dB, pink noise, 1m, 20v, 40Hz-19kHz
• Nominal Impedance: 8 ohms, 3.2 ohm minimum at 70Hz
Speakers
High-Frequency Drivers
K-771 compression driver with extended phase plug on a K-792 horn
Midrange Drivers
K-1133-HP 3" compression driver on K-406M Tractrix horn with Mumps technology
Bass Drivers
K-281 12" woofer in a horn-loaded vented system
Crossover Information
425Hz, 2900Hz
Dimensions
Width
24.5 inch(es) / 62.23 cm
Height
39.13 inch(es) / 99.38 cm
Depth
25.5 inch(es) / 64.77 cm
Weight
92.99 kg (each)
