Features
CAST IRON COOKING GRIDS
Broil King’s cast iron grids are reversible. One side is pointed
to give you perfect grill marks, while the other side is grooved
to capture juices for continuous basting while cooking.
Crown™ series feature a 3 position cooking grid system.
DUAL-TUBE™ BURNERS
Patented Dual-Tube™ burners ensure a consistent flame from
front to back, providing even and efficient heat distribution at
the cooking surface.
FLAV-R-WAVE™ COOKING SYSTEM
The stainless steel Flav-R-Wave™ cooking system provides
superior heat distribution, protects the burner and vapourize
drippings for great barbecue flavour.
THERMA-CAST ALUMINUM COOKBOX
Therma-Cast Aluminum Cookbox
PATENTED DESIGN
Patented Design Powerful Even Heat
PORCELAIN COATED WARMING RACK
Porcelain Coated Warming Rack
FOLD-DOWN LOCKING SHELVES
Fold-Down Locking Shelves
DURABLE LOCKING CASTERS
Durable Locking Casters
CABINET TANK DRAWER
Cabinet Tank Drawer
TOOL HOOKS
Side Shelf Tool Hooks
ELECTRONIC IGNITION.
Reliable Electronic Ignition
Specifications
General
Series Name
Crown 420 Shadow
Color
Black
Manufacturer Color
Black
Type
Cart
Fuel Type
Natural Gas
Cooking Area
Total Cooking Area
630 in²
Primary Area
460 in²
Secondary Area
170 in²
Cooking System
Burners
4
Main Burner Output
40000 BTU
Features
Technologies
• Burners: Four stainless steel Dual-Tube™ burners
• Flavour System: Stainless steel Flav-R-Wave™ cooking system
• Heat Control: Linear-flow™ valves with 180° precision control
• Ignition: Sure-Lite™ electronic ignition system
• Flavour System: Stainless steel Flav-R-Wave™ cooking system
• Heat Control: Linear-flow™ valves with 180° precision control
• Ignition: Sure-Lite™ electronic ignition system
Electronic Ignition
Yes
Warming Rack
Yes
Additional Information
• Performance: 40,000 BTU main burner output
• Cooking Grids: Heavy-duty cast iron cooking grids
• Total Cook Space: 630 sq-in / 4,065 sq cm total cooking space including porcelain-coated warming rack
• Primary Cook Space: 460 sq-in / 2,968 sq cm primary cook space
• Thermometer: Premium thermometer for accurate temperature readings
• Cabinet and Lid: Rigid steel cabinet with black powder coat painted doors and porcelain enameled lid
• Durability: Durable cast aluminum cookbox
• Lid Design: Double-walled lid with cast aluminum end caps
• Side Shelves: Premium powder-coat painted fold-down side shelves
• Casters: Four large 3-in / 7.6 cm locking casters
• Construction: Rust-resistant zinc-coated steel components
• Cooking Grids: Heavy-duty cast iron cooking grids
• Total Cook Space: 630 sq-in / 4,065 sq cm total cooking space including porcelain-coated warming rack
• Primary Cook Space: 460 sq-in / 2,968 sq cm primary cook space
• Thermometer: Premium thermometer for accurate temperature readings
• Cabinet and Lid: Rigid steel cabinet with black powder coat painted doors and porcelain enameled lid
• Durability: Durable cast aluminum cookbox
• Lid Design: Double-walled lid with cast aluminum end caps
• Side Shelves: Premium powder-coat painted fold-down side shelves
• Casters: Four large 3-in / 7.6 cm locking casters
• Construction: Rust-resistant zinc-coated steel components
Dimensions
Grill Size
54"
Overall Width
53.75 inch(es) / 136.53 cm
Overall Height
46.5 inch(es) / 118.11 cm
Overall Depth
24 inch(es) / 60.96 cm
Shipping Dimensions
Width
29 inch(es) / 73.66 cm
Height
25 inch(es) / 63.5 cm
Depth
24 inch(es) / 60.96 cm
Weight
144.01 lb(s) / 65.32 kg
Warranty
Warranty
• Stainless Steel / Porcelain Steel Lid Components — 25 Years
• Cast Aluminum Cookbox / Components — 25 Years
• Stainless Steel Cookbox — 25 Years
• Cast Iron — 2 Years
• Heat Medium — 3 Years
• Burners — 10 Years
• Side Burner — 2 Years
• Rear Burner — 10 Years
• Stainless Steel Components — 5 Years
• Remaining Parts & Paint — 2 Years
• Cast Aluminum Cookbox / Components — 25 Years
• Stainless Steel Cookbox — 25 Years
• Cast Iron — 2 Years
• Heat Medium — 3 Years
• Burners — 10 Years
• Side Burner — 2 Years
• Rear Burner — 10 Years
• Stainless Steel Components — 5 Years
• Remaining Parts & Paint — 2 Years
Documents
